    Flanges

    Weld neck, blind and slip-on flanges in Duplex F51, Super Duplex F53/F55 and 6Mo alloys — 1/2" to 48" OD across all pressure classes, ASME B16.5, B16.47 and API 6A.

    ACTUAL PROJECT / OFFSHORE OIL & GAS

    C63000 parts for an offshore fire safety system

    A blind flange, stud bolts and nuts in C63000 nickel aluminium bronze, supplied with the client's specified gasket. Built around the client's drawings and specifications, the package was supplied on time and air-freighted to the client for offshore use.

    The client came to EMG through a colleague's referral after being unable to source the required parts from other Australian suppliers, and reported being very happy with the quality.

    Read the Case Study
    C63000 stud bolts and nuts with an EMG-marked blind flange and accompanying blue gasket for an offshore fire safety system
    The supplied offshore package: C63000 blind flange, stud bolts and nuts, with the specified gasket. Actual project photograph.
    Machined face and four bolt holes of the supplied EMG C63000 blind flange
    A closer look at the blind flange face and bolt-hole geometry. Actual supplied part.
    Supplied stud bolt and two nuts with a visible C63000 marking on the upper nut
    C63000 stud bolt and nuts from the same offshore fire safety order. Markings do not replace material records.

    Project-specific supply outcome; not a stock or guaranteed lead-time offer. C63000 applies to the metal parts shown, not the gasket. Future requirements are buy-to-order, with quoted lead time and specification review.

    Large-diameter duplex weld neck flange with raised face and bolt holes
    Weld neck, blind and slip-on flanges in Duplex, Super Duplex and 6Mo
    EN 10204 3.1 Certified
    ISO 9001 Quality
    OVERVIEW

    Overview

    EMG offers a broad stock program of high-quality weld neck, blind and slip-on flanges in Duplex (F51 / UNS S31803 / S32205), Super Duplex (F53 / UNS S32750, F55 / UNS S32760), and 6% Moly alloys. Available from 1/2 inch up to 48 inch OD in all pressure classes, our flanges are designed to ASME B16.5, ASME B16.47 (Series A and B) and API 6A standards. Every flange in our portfolio meets or exceeds international testing standards including ASTM A182, NORSOK M-630 (D44/D54) and Shell MESC SPE 76-212. All incoming materials undergo in-house quality verification — chemical analysis, ultrasonic examination, hardness testing and dye-penetrant inspection.

    With NORSOK M-650 approved supply routes and a unique stock position, our flanges are trusted across global energy, desalination, and heavy industrial projects — precision-engineered for full compatibility wherever reliability is critical.

    WHERE THEY ARE SPECIFIED

    Typical Applications

    01Offshore oil & gas topside and subsea piping
    02Petrochemical processing plants
    03Desalination and seawater service
    04Power generation and steam systems
    05Wellhead and Christmas tree assemblies (API 6A)
    06LNG and chemical plant flanged joints
    SUPPLY SCOPE

    Flange Types We Supply

    Weld neck flanges (WN) — raised face, RTJ and flat face
    Blind flanges (BL)
    Slip-on flanges (SO)
    Socket weld flanges (SW)
    Threaded flanges (TH)
    Lap joint flanges and stub ends
    Long weld neck and orifice flanges
    Anchor / spectacle blinds and spacer-spades
    MATERIAL RANGE

    Common Materials & Grades

    C63000 nickel aluminium bronze — drawing-led blind flange enquiriesDuplex F51 — UNS S31803 / S32205Super Duplex F53 — UNS S32750Super Duplex F55 — UNS S327606% Moly UNS S31254 (254 SMO)Nickel Alloy 625 (UNS N06625)Nickel Alloy 825 (UNS N08825)SS 304 / 304L (F304/F304L)SS 316 / 316L (F316/F316L)SS 321 (F321), SS 347 (F347)Low Alloy F11 / F22 / F91Carbon Steel A105
    VERIFICATION

    Standards & Documentation

    ASME B16.5 — pipe flanges and flanged fittings (1/2" – 24")
    ASME B16.47 Series A & B — large diameter flanges (26" – 60")
    API 6A — wellhead and Christmas tree equipment
    ASTM A182 — forged or rolled alloy and stainless flanges
    NORSOK M-630 (MDS D44/D54) and M-650 qualified supply
    Shell MESC SPE 76-212 compliance
    EN 10204 3.1 / 3.2 MTRs with full heat-number traceability
    In-house PMI, hardness, ferrite, UT and DP testing
    FREQUENTLY ASKED QUESTIONS

    Technical FAQs

    Which flange grade should I specify for Super Duplex service?

    +
    For Super Duplex flanges, ASTM A182 F53 (UNS S32750) and F55 (UNS S32760) are the two recognised grades. F55 contains slightly higher chromium and tungsten and is often specified for the most aggressive chloride and CO₂ environments. Both should comply with NORSOK M-630 MDS D54 for North Sea projects.

    What is the largest flange you can supply?

    +
    Standard flanges are supplied from 1/2 inch to 24 inch under ASME B16.5, and from 26 inch to 60 inch under ASME B16.47. Larger custom flanges are available on a project basis with full forging and machining traceability.

    Do you supply API 6A flanges for wellhead service?

    +
    Yes. We supply API 6A 6BX and 6B flanges in PSL-3/PSL-4 categories for wellhead and Christmas tree equipment, with full material certification and dimensional reports.

    Are flanges supplied with NORSOK M-630 / M-650 documentation?

    +
    Yes. Duplex, Super Duplex and 6Mo flanges are supplied with NORSOK M-630 MDS sheets and traceable to NORSOK M-650 qualified manufacturers. Documentation packs include MTRs, dimensional reports, PMI logs and any required NDE records.
